Hanna HI3001D EC probe with 4 platinum rings, plastic body, NTC temperature sensor, in-line mounting
Conductivity probe for HI943500 series controllers with internal NTC temperature sensor and PEI/PVDF body for immersion.
Four platinum rings
Operating temperature from 0 to 80°C
Maximum pressure 6 bar
Product Versions:
- HI3001; 3m cable without connector
- HI3001D; 3m cable with DIN connector
- HI3001D/10; 10m cable with DIN connector
Supplied in a box along with the electrode quality certificate.
It is Designed for conductivity measurement in industrial applications, with the option of in-line (continuous flow) or immersion installation. Its 4-ring technology provides accurate and stable measurements, with automatic temperature compensation thanks to the built-in NTC sensor. This probe measures the electrical conductivity of a solution, typically expressed in µS/cm or mS/cm. Conductivity allows for the evaluation of dissolved salt concentrations and the control of water treatment processes, dosing, and water quality.
Suitable probe for:
- Water treatment and purification.
- Industrial process control.
- Reverse osmosis and desalination systems.
- Water quality control.
- Chemical dosing installations.
- Wastewater monitoring.
- Processes requiring continuous conductivity measurement.
- Installations in pipes, tanks, or cells flow.
