Sodeca CJTXR-FE Fan with certified transmission 400 ºC/2h
Ecology unit with certified transmission 400 ºC/2h, with a robust reaction turbine and high-efficiency electrostatic filters
Approval according to EN 12101-3 standard, with certification no.: 2797 CPR 840443 (F400)
Records for the removal of filters for maintenance.
25mm rock wool insulation in panels.
In the quote request form, please specify the model and any other information that may help us provide you with the most suitable product (flow rate, three-phase/single-phase, number of poles, dimensions, materials, etc.).
Filtration stages:
- Electrostatic filter: Removes ionized grease particles of medium and small size.
- Washable G2 filter: Retains large grease particles.
- Activated carbon filter (optional): Eliminates low concentrations of odor particles.
Motor:
- Three-phase 230/400 V 50 Hz (up to 4 kW) and 400/690 V 50 Hz (power ratings above 4 kW).
- Class F motors with ball bearings and IP55 protection.
- IE3 efficiency motors.
- Operating temperature: -25°C to +50°C.
Fan:
- Robust, double-inlet jet turbine.
- Maximum air temperature: Service S1: +5°C to +75°C continuous.
- S2 Service: 400°C/2h.
Features:
- 25 mm rock wool insulation in panels.
- Self-cleaning reaction turbine.
- Access ports for filter removal for maintenance.
- Inspection cover for maintenance.
- Grease collection tray.
- Integrated connection box.
- High-efficiency electrostatic filter (95% ePM1) 230 V (+-7.5%) 50 Hz.
- Approval According to EN 12101-3, with certification no.: 2797 CPR 840443 (F400), for use outside the fire zone.
Finish:
Structure in aluminum profiles and pre-lacquered outer sheet metal.
On request:
- Particle sensor for automatic control.
- Special windings for different voltages and frequencies.
- Possibility of adapting the transmission mounting to the left or right.
